AsRock B650M-HDV/M.2
AM5, AMD B650, mATXPrice in EUR including VAT, free shipping
Delivered Mon, 30.12.
Only 1 item in stock
Only 1 item in stock
Product details
The ASRock B650M-HDV/M.2 is equipped with the B650 chipset for AMD's Ryzen processors of the 7000 series and offers numerous features for gamers. Since the Ryzen 7000 series processors require a socket
due to the support of PCIe 5.0 and the extended power supply, the socket AM5 (LGA 1718) is used on the 600 series mainboards. Despite the increased number of pins, the actual size of the socket remains identical to older sockets, so that most CPU coolers for socket AM4 can also be mounted on the mainboard. The ASRock B650M-HDV/M.2 offers good overclocking potential. The high-quality voltage converters with 8+2+1 virtual phases convince with a stable power supply of the CPU to achieve high clock rates even over a longer period of time. Dr.MOS allows automatic adjustment of VRM voltage and frequency modulation. In addition, extensive VRM heat spreaders ensure cool temperatures.
| Processor family | Ryzen 3 7th Gen, Ryzen 5 7th Gen, Ryzen 7 7th Gen, Ryzen 9 7th Gen |
| Memory type | DDR5 RAM |
| Internal connection options | 24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 PCIe (1x), S-ATA III (4x) |
| Peripheral connections | USB 2.0 Type-A (8x), USB 3.2 Gen 1 (6x), USB 3.2 Gen 2 (1x), USB Type-C (1x) |
| Item number | 25429217 |
| Manufacturer | |
| Category | |
| Manufacturer no. | 90-MXBLA0-A0UAYZ |
| Release date | 10.3.2023 |
| Sales rank in Category Motherboards |
| Form factor | Micro ATX (mATX) |
| Processor socket | AM5 |
| Chipset | AMD B650 |
| Mainboard features | Front panel audio connector, Trusted Platform Module |
| Operating system compatibility | Windows 10 |
| Peripheral connections | USB 2.0 Type-A (8x), USB 3.2 Gen 1 (6x), USB 3.2 Gen 2 (1x), USB Type-C (1x) |
| BIOS type | EFI AMI |
| Processor family | Ryzen 3 7th Gen, Ryzen 5 7th Gen, Ryzen 7 7th Gen, Ryzen 9 7th Gen |
| Memory form factor | DIMM |
| Number of memory modules (RAM) | 2 x |
| Max. memory (RAM) | 96 GB |
| Memory type | DDR5 RAM |
| RAM buffer | Unbuffered |
| Video connections | DisplayPort (1x), HDMI (1x) |
| Video connection version | Display port 1.4, HDMI 2.1 |
| Multi-GPU technology | AMD CrossfireX |
| Network connections | RJ45 (1x) |
| Ethernet controller brand | Realtek |
| Ethernet controller | Realtek RTL8125-BG |
| Max. port speed | 2.50 Gbit/s |
| Chip | Realtek ALC897 |
| Audio channel | 7.1 Channel |
| Audio Connections | HDMI (1x) |
| Internal connection options | 24-pin ATX power connector (1x), 8-pin ATX 12V (1x), M.2 PCIe (1x), S-ATA III (4x) |
| Expansion slot | PCI Express x1 (1x), PCI Express x16 (2x) |
| PCI express version (max.) | 4 |
| Power connectors | 8-pin PCI-E |
| Scope of delivery | 2 x Serial ATA cable |
| Length | 226 mm |
| Width | 244 mm |
| Height | 260 mm |
| Weight | 1218 g |
| Length | 26.10 cm |
| Width | 27.30 cm |
| Height | 6.10 cm |
| Weight | 1.20 kg |
