Product details
The Prime Z390 series offers a professional setup and is aimed at users who work with PCs daily, as well as content creators, with versatile specifications and features. Along with the advantages of the latest processors, the essential Asus design, and sophisticated technology, the Prime Z390-P provides a wealth of performance optimization options that are realized through intuitive software and firmware functions. With specialized software and extensive optimization options, the Prime Z390-P simplifies CPU overclocking, allowing both beginners and experienced professionals to build a well-tuned system. A new memory trace layout offers stability and compatibility for both traditional DIMMs and RGB-lit memory, enabling you to combine a wide range of DRAM kits in your system. The Prime Z390-P is designed for PC builders who value Asus's renowned quality and performance. More CPU cores present challenges for power supply, which is why the Prime Z390-P features additional phase power connectors and comprehensive cooling functions for optimal performance. The Prime Z390-P boasts the most extensive cooling control ever, configurable via Fan Xpert 4 and the UEFI BIOS. With 5050 RGB strips connected to the RGB header, you can create your own stunning lighting scenarios with multicolored static, blinking, fading, and strobe effects. Intelligent design and premium hardware deliver unprecedented audio quality.
Processor family | Celeron, Core i3 8th Gen, Core i3 9th Gen, Core i5 8th Gen, Core i5 9th Gen, Core i7 8th Gen, Core i7 9th Gen, Core i9 9th Gen, Pentium |
Memory type | DDR4-RAM |
Number of memory modules (RAM) | 4 x |
Internal connection options | S-ATA III (4x) |
Mainboard features | Front panel audio connector |
Item number | 9854343 |
Manufacturer | ASUS |
Category | Motherboards |
Manufacturer no. | 90MB0XX0-M0EAY0 |
Release date | 8.10.2018 |
External links |
Form factor | ATX |
Socket | LGA 1151 |
Chipset | Intel Z390 |
Mainboard features | Front panel audio connector |
Operating system compatibility | Windows 10, Windows 10 Home |
BIOS type | UEFI AMI |
Processor family | Celeron, Core i3 8th Gen, Core i3 9th Gen, Core i5 8th Gen, Core i5 9th Gen, Core i7 8th Gen, Core i7 9th Gen, Core i9 9th Gen, Pentium |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 4 x |
Max. memory (RAM) | 128 GB |
Memory chip | DDR4-2133, DDR4-2400, DDR4-2666, DDR4-2800, DDR4-3000, DDR4-3200, DDR4-3300, DDR4-3333, DDR4-3400, DDR4-3466, DDR4-3600, DDR4-3733, DDR4-3866, DDR4-4000, DDR4-4133, DDR4-4266 |
Max. RAM OC | 4133 MHz |
Supported memory speed | 2133 MHz, 2400 MHz, 2666 MHz, 3000 MHz, 3200 MHz |
Memory type | DDR4-RAM |
RAM buffer | Unbuffered |
Video connections | DisplayPort (1x), HDMI (1x) |
Video connection version | HDMI 1.4 |
Multi-GPU technology | AMD CrossfireX |
Network connections | RJ45 (1x) |
Ethernet controller brand | Realtek |
Ethernet controller | Realtek 8111H |
Chip | Realtek ALC887 |
Audio channel | 8.0 Channel |
Audio Connections | Coaxial S/PDIF (1x), Jack 3.5mm (4x) |
Internal connection options | S-ATA III (4x) |
Expansion slot | PCI Express x1 (4x) |
Number of fan connector | 3 |
Power connectors | 24-pin EATX, 8-pin EATX 12V |
CO₂-Emission | |
Climate contribution |
Scope of delivery | S-ATA cable, User manual |
Length | 234 mm |
Width | 305 mm |
Height | 234 mm |
Length | 33.30 cm |
Width | 26.90 cm |
Height | 5.40 cm |
Weight | 1.14 kg |
Product Safety |
Specifications may include unverified machine translations.
