Fractal Define 7 Solid

ATX, mATX, Mini-ITX, E-ATX
Currently out of stock

Colour

Product details

The Define 7 sets standards in terms of quality, quiet operation, versatility, and a modern, minimalist design. Thanks to its modular interior with dual layout, the Define 7 effortlessly supports motherboards up to E-ATX standard and offers extensive cooling options with space for up to 9 fans and a 420 mm radiator. Innovative multi-brackets also allow any unused fan position to be converted into a mount for HDDs, SSDs, pumps, or reservoirs. The aluminum front features a magnetic closure mechanism and can be mounted on either side. For even better access to the interior, the top panel can be completely removed. The timeless, minimalist design and the variety of innovative features make the Fractal Design Define 7 the ideal choice for all PC users who have high standards for design, functionality, and versatility, while allowing space for individual builds of all kinds.

Key specifications

PC case design
Midi Tower
Max. length graphics card
440 mm
Front connectors
1x USB 3.2 Gen2 Type-C2x USB 2.02x USB 3.0Audio in/outPower buttonReset button
PC case features
Front flapModular HDD cage
Max. height CPU cooler
185 mm
Item number
12757904

General information

Manufacturer
Fractal
Category
PC case
Manufacturer no.
FD-C-DEF7A-04
Release date
19.2.2020
External links

Colour

Colour
BlackWhite
Exact colour description
BlackWhite

Material

Material group
Metal
Material
Steel

PC case properties

PC case design
Midi Tower
Form factor
ATXE-ATXMicro ATX (mATX)Mini-ITX
"Number of 2.5""/3.5"" combination slots"
6 x
"Number of 2.5"" drive slots"
2 x
Number of expansion card slots
7 x
Max. length graphics card
440 mm
Max. height CPU cooler
185 mm
Max length of power supply
300 mm
PC case features
Front flapModular HDD cage

Connections

Front connectors
1x USB 3.2 Gen2 Type-C2x USB 2.02x USB 3.0Audio in/outPower buttonReset button

Cooling properties

Number of fans
3 x
Number of fan slots
9 x
Fan location
Bottom sideFront sideRear sideTop side
Number of radiator mounts
3
Radiator locations
Bottom sideFront sideRear sideTop side
Cooling properties
Water cooling possible

Front side

LED colour
without LED
Fans included
2x 140mm
Fan mount locations
3x 120mm3x 140mm
Radiator mount locations
1x max. 360mm

Rear side

LED colour
without LED
Fans included
1x 140mm
Fan mount locations
1x 120mm1x 140mm
Radiator mount locations
1x max. 120mm

Bottom side

Fans included
Optional fan
Fan mount locations
2x 120mm2x 140mm
Radiator mount locations
1x max. 120/240mm

Top side

Fans included
Optional fan
Fan mount locations
2x 140mm
Radiator mount locations
1x max. 280mm

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
Installation material

Product dimensions

Height
47.50 cm
Length
54.70 cm
Width
24 cm
Weight
13.50 kg

Package dimensions

Length
64 cm
Width
35.50 cm
Height
55 cm
Weight
16.35 kg
