Fractal Define 7 Solid

ATX, mATX, Mini-ITX, E-ATX

Colour

Product details

Midi-Tower by Fractal Design in black and white, for mainboards up to E-ATX (285 mm), with sound insulation & dust filters, high air & water cooling support, incl. 3x 140 mm PWM fans & fan hub, vertical expansion slots.

Key specifications

PC case design
Midi Tower
Max. length graphics card
440 mm
Front connectors
1x USB 3.2 Gen2 Type-C,
2x USB 2.0,
2x USB 3.0,
Audio in/out,
Power button,
Reset button
PC case features
Front flap,
Modular HDD cage
Max. height CPU cooler
185 mm
Item number
12757904

General information

Manufacturer
Category
Manufacturer no.
FD-C-DEF7A-04
Release date
19.2.2020
External links

Colour

Colour group
Black,
White
Exact colour description
Black,
White

Material

Material group
Metal
Specific material description
Steel

PC case properties

PC case design
Midi Tower
Form factor
ATX,
E-ATX,
Micro ATX (mATX),
Mini-ITX
"Number of 2.5""/3.5"" combination slots"
6 x
"Number of 2.5"" drive slots"
2 x
Number of expansion card slots
7 x
Max. length graphics card
440 mm
Max. height CPU cooler
185 mm
Max length of power supply
300 mm
PC case features
Front flap,
Modular HDD cage

Connections

Front connectors
1x USB 3.2 Gen2 Type-C,
2x USB 2.0,
2x USB 3.0,
Audio in/out,
Power button,
Reset button

Cooling properties

Number of fans
3 x
Number of fan slots
9 x
Fan location
Bottom side,
Front side,
Rear side,
Top side
Number of radiator mounts
3
Radiator locations
Bottom side,
Front side,
Rear side,
Top side
Cooling properties
Water cooling possible

Front side

LED colour
without LED
Fans included
2x 140mm
Fan mount locations
3x 120mm,
3x 140mm
Radiator mount locations
1x max. 360mm

Rear side

LED colour
without LED
Fans included
1x 140mm
Fan mount locations
1x 120mm,
1x 140mm
Radiator mount locations
1x max. 120mm

Bottom side

Fans included
Optional fan
Fan mount locations
2x 120mm,
2x 140mm
Radiator mount locations
1x max. 120/240mm

Top side

Fans included
Optional fan
Fan mount locations
2x 140mm
Radiator mount locations
1x max. 280mm

Scope of delivery

Scope of delivery
Installation material

Product dimensions

Height
47.50 cm
Length
54.70 cm
Width
24 cm
Weight
13.50 kg

Package dimensions

Length
64 cm
Width
35.50 cm
Height
55 cm
Weight
16.35 kg

Legal Notice

Product Safety

Here you can see the lowest price of the day over time. Learn more

3 months
All
3 months
All

Reviews & Ratings

Translation: machine translated
Very good85/100
PC Games Hardware Logo
PC Games HardwareSingle testReleaseJune 2020

... However, the three 140 mm fans (fan positions see test table) are responsible for the good to very good cooling performance (CPU: 60 °C/GPU: 70 °C/interior: 38 °C). Thanks to additional insulation for the door and the rear side panel, only a low noise level of 1.1/1.1 sone emanates from the interior, which holds a maximum of 58.8 litres...
