Fractal Era ITX - Carbon TG

Mini ITX
Currently out of stock

Product details

With Era, our ambition was to create the perfect Mini-ITX case - a compact chassis free from the excessiverestrictions traditionally associated with small form factor systems. The result is a unique and
elegantly understated feat of
both design and technical engineering.

Era's aluminum exterior comes in a variety of shades to pair with top inserts ranging from premium wood to tempered glass, letting it stand out or blend into any environment. Despite a modest 16 liter footprint, it readily accommodates dual slot GPUs, AIO water cooling units up to 240 mm, high-end processors and up to four storage devices, all thanks in part to an innovative flexible PSU mounting system. Optimal airflow and component cooling are ensured through its efficient chimney design.

Compact, sophisticated and stylish, Era redefines small form factor with an exceptional design that embraces the power and functionality of professional grade hardware.

Key specifications

PC case design
Mini Tower
Number of 3.5" drive slots (internal)
1 x
"Number of 5.25"" drive slots"
0 x
Max. length graphics card
295 mm
Front connectors
1x USB 3.2 Gen2 Type-C
2x USB 3.0
Audio in/out
Max. height CPU cooler
120 mm
Item number
12860111

General information

Manufacturer
Category
Manufacturer no.
FD-CA-ERA-ITX-BK
Release date
6.3.2020
External links

Colour

Colour group
Black
Exact colour description
Carbon

Material

Material group
Metal
Plastic
Specific material description
Aluminium
Steel

PC case properties

PC case design
Mini Tower
Form factor
Mini ITX
"Number of 5.25"" drive slots"
0 x
Number of 3.5" drive slots (internal)
1 x
"Number of 2.5"" drive slots"
2 x
Number of expansion card slots
2 x
Max. length graphics card
295 mm
Max. height CPU cooler
120 mm
Max length of power supply
160 mm

Connections

Front connectors
1x USB 3.2 Gen2 Type-C
2x USB 3.0
Audio in/out

Cooling properties

Number of fans
2 x
Number of fan slots
5 x
Fan location
Bottom side
Rear side
Top side
Number of radiator mounts
1
Radiator locations
Top side
Cooling properties
Push/pull possible
Water cooling possible

Rear side

Fans included
1x 80mm
Fan mount locations
1x 80mm

Bottom side

Fans included
Optional fan
Fan mount locations
2x 140mm

Top side

Fans included
Optional fan
Fan mount locations
2x 120mm
Radiator mount locations
1x max. 120mm
1x max. 240mm

HDD Cage

Fan mount locations
1x 80mm
Radiator mount locations
1x max. 240mm

Scope of delivery

Scope of delivery
Installation material

Product dimensions

Height
31 cm
Length
32.50 cm
Width
16.60 cm
Weight
4.20 kg

Package dimensions

Length
43.70 cm
Width
39 cm
Height
25.20 cm
Weight
5.04 kg
