Shelly dimmer 2
Dimming actuator
Questions about Shelly dimmer 2
What would you like to know?
0 questions and answers
Helpful answer
I have a Feller EDIZIOdue push-button in use. This works without any problems. Press push-button to switch light "On" or "Off". Press and hold the push-button to dim the light "up" or "down".
Helpful answer
Not compatible with sonoff, works with WiFi
Helpful answer
Unfortunately, I can't tell you anything about this yet. Our purchasing department is of course always endeavouring to pick up and offer the products as quickly as possible.
We are sorry to hear that there has been a problem. You are welcome to submit a corresponding product rating.
Helpful answer
I recommend you ask the question in the Shelly forum. The best thing to do there is to explain what you mean by "digital switching and indicator lamp".
Helpful answer
Press twice briefly to set it to 100%. Press once to set the last brightness
Yes, but both toggle switches must be connected to the Shelly and the lamp to the Shelly output.
Yes, can be set as with all Shellys. Screenshot: https://paste.pics/PMX10
Helpful answer
If the switch can also be "switched over" as a push-button (switching state only when pressed on), you can even use the dimming function by setting an additional function for the long push-button action. However, the dimming would then only go brighter or darker, then you would have to switch off again to start at the initial value. Most switches can only switch on and off, so you have to set the Shelly so that a toggle switch is connected and the Shelly switches the dimmer on when the input is on and switches the dimmer off again when the input is off. Ideally, you have a double push-button for the dimmer, then both inputs can be used with a short press to switch on/off and with a long press the brightness changes.
The Shellys offer APIs with REST, for example, so almost anything is possible. Of course, your Sonoff must be able to call this.
No, that's not possible. The "stupid" Feller dimmer and the Shelly dimmer do not communicate with each other. That is why a combination of both devices is not possible. Either no Shelly dimmer or you have to remove the Feller dimmer. If the Shelly dimmer is used, it is the only device that is allowed to influence the voltage in terms of dimming for the corresponding lamp(s). https://shelly.cloud/knowledge-base/devices/shelly-dimmer-2/ https://shelly.cloud/documents/user_guide/shelly_dimmer_2_multi_language.pdf
As it looks, this is really not the right illustration! The Shelly Dimmer 2 has 5 connections as you say. https://shelly.cloud/knowledge-base/devices/shelly-dimmer-2/ (unfortunately only English). This picture is of the Shelly Dimmer 1 and should be replaced by Digitec :-( ..... embarrassing ...Greetings
If I understood correctly, it can work with the timer, but over time would loose precision as without wifi it can't synchronise with the time server on the internet
Hello The default after power failure can be defined in the app or WebUI. The selectable values are On, Off, as before.
Helpful answer
No, only the Shelly dimmer can also dim!
