TE Sensors Vacuum switch XMLAM01V2S12 Manufacturer :TE Sensors Designation :Vacuum switch 1 bar, 1W Type :XMLAM01V2S12 Suitable as a monitor :yes Suitable as a 2-point controller :no Suitable as a limiter :yes Max. Working pressure :-40 hPa Switch-on pressure :-0.76..-0.04 bar Initial setting :-760..-40 hPa Switch-off pressure :-1..-0.28 bar Final setting :-1000..-280 hPa Pressure switching differential :0.23999999 bar Max. test pressure :9 bar Burst pressure :1 bar Test pressure :9 bar Burst pressure :18 bar Medium temperature :0..70 °C Connection :Female thread gas cylindrical (BSPP) Thread size :1/4 inch Rated operating voltage Ue at AC 50 Hz :120..240 V Rated operating voltage Ue at AC 60 Hz :120...240 V Rated operating voltage Ue at DC :250 V Initial value Pressure measuring range :0 Pa Final value Pressure measuring range :0 Pa Rated operating power at AC-3, 400 V :0 kW Switching capacity at AC-3, 240 V :0 kA Rated operating current Ie at AC-1, 400 V :0 A Rated operating current Ie at AC-3, 400 V :0 A Number of auxiliary contacts as changeover contacts :1 Type of electrical connection :Screw connection Adjustable current range :0 A With manual override :no With manual on/off switch :no Electronic version :no With display :no Explosion-proof :no Protection class (IP) :IP66 Protection class (NEMA) :other Height :113 mm Width :35 mm Depth :75 mm TE Sensors vacuum switch XMLAM01V2S12: more details XMLA vacuum switch - 1 bar, fixed hysteresis, 1 switching point, 1 NC or 1 NO contact, connection terminals. , EAN: 3389110748055.
