Murr Elektronik Safety transformer

250 VA. Technical data: . Number of outputs: 1 x - Number of inputs: 1 x - Output voltage: 24 V/AC - Output voltage (number x voltage): 1 x 24 V/AC - Input voltage (number x voltage): 1 x 230 V/AC,400 V/AC - Input voltage (num): 230 V/AC,400 V/AC - Input current: 1.35 A - Frequency (details): 50 Hz - Content: 1 pc. - Insulation class: T 40/B - Power: 250 VA - Dimensional data: 108 x 96 x 102 mm - Product type: Safety isolating transformer - Product dimension, width: 96 mm - Product dimension, height: 102 mm - Product dimension, length: 108 mm - Type (manufacturer type): 86365 - Ambient temperature (max.): +40 °C - Ambient temperature (min.): +40 °C - Ambient temperature (max.): +50 °C): +40 °C - Ambient temperature (min.): -20 °C - Further technical data: Mounting type: slotted hole mounting and snap-on to mounting rail TH35 (EN 60715).Mounting dimensions a x b x c: 86.5 x 84 x 4.8 mm.Hole Ø: 4.8 mm x 8.4 mm.Test insulation voltage: 4 kV (prim./sec.) - Approvals, standards: EN 61558-1, EN 61558-2-6, EN 62041 category 0.
